Presenting
Access Control With
Microsoft Access
Use The Full Off-The-Shelf Version Of MS Access
Or Use Our Included Runtime Version
  • Card Access For Perimeter & Internal Building Security
  • Alarm Monitoring And Annunciation
  • Programmable Elevator Floor Access Control
  • Parking Management With Every Variation Of Anti-Pass-Back, Space Counting, Lot Full Sign Control, Reserved Space Allocation Specific To Each Tenant, And Revenue Fee Billing Based On Card Use "In Time"
  • Built-In Digital I.D. Imaging Included At No Cost
  • Pre-defined and custom reports: View
-And The Source Code is Included-
Our popular Access Central System provides total facility security and parking Management for any number of entry points, and uses Microsoft's powerful MS Access platform for security management.

We use the off-the-shelf version of MS Access so customers can change it to another language, design custom forms,  and create reports using the powerful Wizards built into the program.

A network of stand-alone card readers simply connect to any "PC" using a two twisted pair cable, phone lines, or fiber optics. Our powerful Access Central software puts an end to costly proprietary systems.


You Have A Choice Of Field Architecture
  • System Bus Connects To A Personal Computer:

  • [View drawing]
    A Simple but powerful solution for most applications
  • System Bus Connects To A Network Controller:

  • [View drawing]
    Use our new high-tech Network Controller instead of a "PC"
System Highlights
(Newest Features)
  • Up to 254 Card Readers/PC
  • Your Choice Of Any Card Technology
  • Emergency Scenario Mode (Check It Out)
  • Stand-Alone Entry Points (No central panels)
  • 65,000 Card Capacity (Expandable To 100,000)
  • NEW Password Manager (Try It)
  • Supports All Card Formats from 1-9 Digits
  • Microsoft NT Support (More)
  • Unlimited Transaction Storage And Reports
  • V.I.P Tracking Displays A List Of Who's In (More)
  • Digital Imaging for I.D. Cards Included At No Charge
  • Monitor & Annunciate Up To 2,000 Alarms
  • Four State Alarm Supervision Option
  • Floor Specific Elevator Control (With Floor Choice auditing)
  • Global Anti-Pass-Back Modes
  • Reader Specific Anti-Pass-Back Modes
  • Space Counting And "Lot Full" Sign Control (More)
  • Tenant Space Allocation.  Limits The Number Of Spaces Each Tenant May Occupy At Any Given Time
  • Hotel Guest Parking Package: (More)
  • Car Pool Enforcement.  Allows Each Pool Member A Separate Access Card, But Accepts Only The First Card Used Each Day
  • Real Time Transaction Printing. Prints events a line at a time as they occur. (More)
  • View Report Samples


When Card Security Counts
Site Code Exclusivity
Most  modern access control systems feature a dazzling  array  of electronic wizardry, but these features accomplish little if  the system itself can be inadvertently, or intentionally compromised by cards the customer does not know about. In today’s fast paced world, that condition is the rule rather than the exception, because most manufactures don't go to the trouble of insuring customer format exclusivity. We do, and always have.  For Differential Optics and Proximity systems, we use a secure encrypted format, and we register every end user's site code, and every card number ever issued to that site code. This involves more clerical overhead, but it's worth it because Toye Corporation customers can rest assured that their systems are secure, and cannot be compromised by cards that they don't know exist.



Special High End Features

Elevator Control Systems
Elevator ControlBoth our "PC" based system and our Smart Cartridge can provide floor specific control to any floor by day, date, time and with holiday exceptions. Using our new P.I.N.. Prox option, cardholders may select their floor from our keypad so that only one floor is enabled per transaction, and so that the cardholder's actual floor selection choice is logged. Our software lets each tenant select its own secure and public access time schedules, when their floors may be accessed, and by whom.

Parking Systems
Our standard software package offers more high end parking features than many systems dedicated exclusively to parking. They include user selectable hard or soft anti-pass-back, timed anti-pass-back, auto re-synch, and car pool enforcement.

Space counting is a standard feature that allows cumulative and differential occupancy counts with lot full sign control. A counter may be incremented or decremented by any number of entrances and exits.

Our tenant specific space allocation module lets you designate a fixed Car Parknumber of free spaces per tenant, and will block free entry for that tenant until an allocated space becomes available.

We offer special report packages such as Tenant Billing that automatically generates monthly invoices to tenants, and it includes the popular Positive Posting feature which automatically voids or validates cards based on invoice payment.

Time Management is another report module that calculates time in the parking lot for billing purposes.

We also offer Touch Screen Cashiering software for parking revenue control. The system uses bar coded tickets for automatic fee calculation. The software supports up to 99 separate validation accounts, and our revenue parking manager software package provides revenue reports and easily configured rate scheduling.

Digital I.D. Systems

Based On New Low Cost Consumer Products You May Already Own

Inkjet or Direct to Card Image Printing
Here's a system that takes advantage of new high tech consumer products to provide a digital I.D. that is superior to those produced by high dollar systems. The photo shown here was taken with a $200.00 digital camera, and printed with and Epson Ink Jet printer which is available for less than $300.00. What you see is the exact quality of the final product, and when laminated, looks even better. Unlike other digital I.D.'s, this card can be printed on both sides at the same time, and is laminated to provide full and permanent protection of the image. The secret to the simplicity of this process is the use of Microsoft Access to compose the I.D. format and maintain permanent records for re-badging. You simply purchase a copy of MS Access, and we provide the setup document with your custom artwork and layout so you don't have to learn the program. The final product is a permanent high quality digital photo identification card with a surface that won't scratch.

High End System Quality At A Fraction Of The Cost

  • Uses Low Cost Color Digital Camera
  • New Inkjet Printer Delivers Twice The Resolution As The Dye Sub Process
  • Polyester Lamination Protects Surface
  • Optional Adhesive Back For Prox Cards
  • Uses Microsoft Access
  • Print Single Or Multiple I.D.'s At Once
  • Simple Process Anyone Can Master
  • Print Both Sides Of The I.D. At Once
We have full color catalog sheets on all our products, and would be happy to send them to you. Simply "click" below and tell us about your application.  If you are in a hurry, you can display, print, or download a full color catalog right now
[View or Download Color Brochures]
If you don't see the functionality you are looking for, tell us what you need. We built our company on custom requirements
Ask Us For More Information...
